MOST CAPABLE & VERSATILE RZR: Go all out with the Ultimate trim featuring RIDE COMMAND® Technology, Rockford Fosgate® premium audio and DYNAMIX 2.0 active suspension to create the perfect ride.
Features
CONTROL IN ANY TERRAIN
: Take on the world's roughest trails with 22" of usable suspension that soaks up all the bumps while DYNAMIX 2.0 unlocks instant control and confidence in virtually any terrain.
ELEVATED OFF-ROAD EXPERIENCE
: Stay connected with RIDE COMMAND integrated into a 7" display, Rockford Fosgate Premium Audio is now louder and better than before and DYNAMIX active suspension continuously adjusts shocks on the fly.
MAXIMUM CONTROL
: Engineered to make you feel like part of the machine.
MOST VERSATILE
: Carve tight terrain with confidence to go anywhere. The tight turn radius of the 96" wheelbase delivers nimble handling in any terrain.
OVERCOME CHALLENGES
: Clear obstacles with ease in a variety of terrain with a capable 14.5" of ground clearance and 30" tires.
PRECISION ACCELERATION
: Designed to deliver power for corner-to-corner performance within the 20-50 MPH range where you crave it most.
RIDER-CENTRIC COMFORT
: Feel the security of the driver-centric cockpit with 2" lower seating, bolstered bucket seats with 4-way adjustability, a tilting and telescoping wheel and look forward to uncompromising sightlines.
RUGGED STRENGTH
: Stronger and more robust in every way that matters.
THRILLING PERFORMANCE
: Taking off-road performance to the next level.
OEM Data
Bakes/Wheels/Tires
Brakes
Front / Rear - 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Calipers Parking - Park In-Transmission
Tires
Front / Rear - 30 x 10-14 MAXXIS Carnivore (8-Ply)
Wheels
Cast Aluminum Front Wheel Size - 14 x 6 Rear Wheel Size - 14 x 7
RIDE COMMAND® 7 in. Glove-Touch Display - DYNAMIX 2.0 Visualizer, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets, Rockford Fosgate Premium Audio (Including 2 Tweeters, 2 Front Speakers, and External 400W Amp) Dual-sweep Analog Dials with 4 in. LCD Rider Information Center - User Selectable Blue / Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet
Electrical System
High Output 900W charging system with sealed electrical
Lighting
Signature White LED, Low / High & Red LED Tail / Brake Lights; Front & Rear LED Accent Lights
Engine
Engine
4-Stroke DOHC Turbocharged
Cylinders
Twin
Displacement
925 cc
Fuel Capacity
12 gal. (45.4 1)
Cooling
Liquid
Horsepower
181 hp
Fuel System
Electronic Fuel Injection
Operational
Suspension
Electronic Control System - DYNAMIX 2.0 Active System
Seating
Bolstered Bucket Seats with 4-way adjustability
Rear Suspension
Trailing Arm & High-Clearance Radius Rods with Stabilizer Bar Usable Travel - 22 in. (55.9 cm) Wheel Travel - 20 in. (50.8 cm) Shocks - FOX 2.5 Podium Live Valve with Bottom-Out Control (Electronically Controlled Damping)
Steering
High Assist Electronic Power Steering with Quick Turn Rack; Race inspired Steering Wheel with Tilt and Telescoping adjustment; Dynamix and Ride Command Push Button Controls
Front Suspension
High-Clearance Dual A-Arm with Stabilizer Bar Usable Travel - 20 in. (50.8 cm) Wheel Travel - 17 in. (43.2 cm) Shocks - FOX 2.5 Podium Live Valve with Bottom-Out Control (Electronically Controlled Damping)
